Carrier Indoor & Outdoor Split Geothermal Heat Pumps - Rev.: 08/10/05
38
Electrical Data
Model
Compressor
HWG
Pump
FLA
External
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse/
HACR
Min
AWG
Max
Wire Ft.
(m)
RLA
LRA
Qty
026
10.3
52
1
0.4
4.0
14.7
17.2
25
10
110 (33.5)
038
16.7
82
1
0.4
4.0
21.0
25.2
40
8
120 (36.5)
049
21.2
96
1
0.4
4.0
25.5
30.8
50
6
160 (48.5)
064
25.6
118
1
0.4
4.0
30.0
36.4
60
6
135 (41.0)
GT-S (38WQS) Electrical Data
GT-PX (50YDS) Electrical Data
GT-GS (50YCS) Electrical Data
Rated Voltage of 208/230/60/1
Min/Max Voltage of 197/254
HACR circuit breaker in USA only
All fuses Class RK-5
Wire length based on one way measurement with 2% voltage drop
Wire size based on 60°C copper conductor
Rated Voltage of 208/230/60/1
Min/Max Voltage of 197/254
HACR circuit breaker in USA only
All fuses Class RK-5
Wire length based on one way measurement with 2% voltage drop
Wire size based on 60°C copper conductor
Model
Compressor
HWG
Pump
FLA
Ext Loop
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse/
HACR
Min
AWG
Max
Wire Ft
(m)
RLA
LRA
Qty
Crank-
case
018
7.1
38.0
1
N/A
0.40
4.0
11.2
12.9
20
12
90 (27.4)
024
10.3
56.0
1
0.17
0.40
4.0
14.4
17.0
25
10
120 (36.6)
030
12.2
67.0
1
0.17
0.40
4.0
16.4
19.4
30
10
100 (30.5)
036
13.5
73.0
1
0.17
0.40
4.0
17.6
21.0
30
10
90 (27.4)
042
16.5
95.0
1
0.17
0.40
4.0
20.7
24.8
40
8
120 (36.6)
048
18.3
109.0
1
0.17
0.40
4.0
22.5
27.1
45
8
110 (33.5)
060
28.9
169.0
1
0.29
0.40
4.0
33.1
40.4
60
6
120 (36.6)
Rated Voltage of 208/230/60/1
Min/Max Voltage of 197/254
HACR circuit breaker in USA only
All fuses Class RK-5
Wire length based on one way measurement with 2% voltage drop
Wire size based on 60°C copper conductor
Model
Compressor
HWG
Pump
FLA
External
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amps
Max
Fuse/
HACR
Min
AWG
Max
Wire Ft
(m)
RLA
LRA
Qty
018
9.0
42.0
1
0.40
4.0
13.4
15.7
20
12
80 (24.4)
024
10.3
56.0
1
0.40
4.0
14.6
17.2
25
10
110 (33.5)
030
12.2
67.0
1
0.40
4.0
16.5
19.6
30
10
100 (30.5)
036
13.5
73.0
1
0.40
4.0
17.8
21.2
30
10
90 (27.4)
042
16.5
95.0
1
0.40
4.0
20.9
25.0
40
8
120 (36.6)
048
18.3
109.0
1
0.40
4.0
22.7
27.3
45
6
180 (54.9)
060
25.0
169.0
1
0.40
4.0
29.3
35.6
60
6
140 (42.7)
