Carrier GT-S - Manual (Page 25)

Two-Stage Indoor Split
Puron
®
Systems
23 Carrier Indoor & Outdoor Split Geothermal Heat Pumps - Rev.: 08/10/05
50YDS049 Part Load With FV4006
20 11.00 4.0 9.2 850 0 0 0 0 0 0 22.3 2.16 15.3 94.3 3.03 3.3
20 11.00 4.0 9.2 1000 0 0 0 0 0 0 22.6 2.07 15.7 90.9 3.20 2.8
30 5.50 1.1 2.5 850 37.1 22.5 1.19 41.1 31.2 - 24.5 2.23 17.1 96.7 3.22 3.4
30 5.50 1.1 2.5 1000 37.8 24.1 1.21 41.9 31.2 - 24.9 2.14 17.6 93.1 3.41 2.9
30 8.25 2.3 5.3 850 37.3 22.5 1.12 41.1 33.3 - 25.3 2.24 18.0 97.6 3.31 3.3
30 8.25 2.3 5.3 1000 38.0 24.1 1.14 41.9 33.3 - 25.7 2.15 18.5 93.8 3.50 2.9
30 11.00 3.9 9.0 850 37.5 22.5 1.08 41.2 34.7 - 25.8 2.25 18.5 98.1 3.36 3.3
30 11.00 3.9 9.0 1000 38.2 24.1 1.10 42.0 34.7 - 26.2 2.16 19.0 94.3 3.55 2.9
40 5.50 1.0 2.3 850 38.8 24.6 1.35 43.4 28.7 - 28.1 2.32 20.4 100.6 3.55 3.5
40 5.50 1.0 2.3 1000 39.6 26.3 1.37 44.2 28.9 - 28.5 2.22 21.0 96.4 3.76 3.0
40 8.25 2.2 5.1 850 39.1 24.7 1.26 43.5 31.0 - 29.4 2.33 21.6 102.0 3.70 3.4
40 8.25 2.2 5.1 1000 39.9 26.4 1.28 44.3 31.2 - 29.8 2.23 22.2 97.6 3.92 3.0
40 11.00 3.7 8.5 850 39.2 24.7 1.24 43.5 31.6 - 30.0 2.34 22.3 102.7 3.76 3.4
40 11.00 3.7 8.5 1000 40.0 26.4 1.26 44.3 31.7 - 30.4 2.24 22.9 98.1 3.98 2.9
50 5.50 0.9 2.1 850 38.4 25.1 1.47 43.4 26.1 0.9 32.1 2.40 24.1 105.0 3.92 3.6
50 5.50 0.9 2.1 1000 39.1 26.9 1.50 44.2 26.1 0.9 32.6 2.30 24.8 100.2 4.15 3.1
50 8.25 2.1 4.9 850 38.7 25.2 1.39 43.5 27.8 0.8 33.6 2.41 25.6 106.6 4.09 3.5
50 8.25 2.1 4.9 1000 39.5 27.0 1.42 44.3 27.8 0.9 34.1 2.31 26.3 101.6 4.33 3.1
50 11.00 3.6 8.3 850 38.8 25.2 1.38 43.6 28.1 0.8 34.4 2.42 26.4 107.5 4.17 3.5
50 11.00 3.6 8.3 1000 39.6 27.0 1.41 44.4 28.1 0.8 34.9 2.32 27.1 102.3 4.41 3.0
60 5.50 0.8 1.8 850 37.2 25.4 1.70 43.0 21.9 1.6 36.3 2.48 27.9 109.5 4.29 3.7
60 5.50 0.8 1.8 1000 37.9 27.2 1.73 43.8 21.9 1.6 36.8 2.38 28.7 104.1 4.53 3.3
60 8.25 2.0 4.6 850 37.9 25.5 1.59 43.3 23.8 1.4 38.0 2.49 29.7 111.4 4.47 3.7
60 8.25 2.0 4.6 1000 38.6 27.3 1.62 44.1 23.8 1.5 38.6 2.39 30.5 105.7 4.73 3.2
60 11.00 3.5 8.1 850 38.1 25.6 1.54 43.4 24.7 1.3 39.0 2.50 30.6 112.5 4.57 3.7
60 11.00 3.5 8.1 1000 38.8 27.4 1.57 44.2 24.7 1.3 39.6 2.40 31.4 106.7 4.84 3.2
70 5.50 0.8 1.8 850 35.1 24.9 1.90 41.7 18.5 2.2 40.4 2.57 31.7 114.0 4.61 3.9
70 5.50 0.8 1.8 1000 35.8 26.7 1.94 42.5 18.5 2.2 41.0 2.46 32.6 108.0 4.88 3.4
70 8.25 2.0 4.6 850 36.1 25.2 1.79 42.3 20.2 2.0 42.4 2.59 33.7 116.2 4.80 3.9
70 8.25 2.0 4.6 1000 36.8 27.0 1.82 43.1 20.2 2.0 43.0 2.48 34.6 109.8 5.08 3.4
70 11.00 3.3 7.6 850 36.6 25.4 1.73 42.5 21.2 1.8 43.6 2.60 34.7 117.5 4.91 3.9
70 11.00 3.3 7.6 1000 37.3 27.2 1.76 43.3 21.2 1.8 44.2 2.49 35.7 110.9 5.20 3.4
80 5.50 0.7 1.6 850 32.7 24.1 2.14 39.9 15.3 2.8 44.5 2.66 35.4 118.5 4.90 4.2
80 5.50 0.7 1.6 1000 33.3 25.8 2.18 40.7 15.3 2.8 45.1 2.55 36.4 111.8 5.18 3.6
80 8.25 1.9 4.4 850 33.8 24.6 2.01 40.7 16.8 2.5 46.6 2.69 37.5 120.8 5.08 4.1
80 8.25 1.9 4.4 1000 34.5 26.3 2.05 41.5 16.8 2.6 47.3 2.58 38.5 113.8 5.37 3.6
80 11.00 3.2 7.4 850 34.4 24.8 1.94 41.0 17.7 2.3 47.7 2.70 38.5 122.0 5.18 4.1
80 11.00 3.2 7.4 1000 35.1 26.5 1.98 41.8 17.7 2.3 48.4 2.59 39.6 114.8 5.48 3.6
85 5.50 0.7 1.6 850 31.4 23.6 2.27 39.1 13.8 3.1 46.3 2.71 37.1 120.4 5.01 4.4
85 5.50 0.7 1.6 1000 32.0 25.3 2.31 39.8 13.9 3.1 47.0 2.60 38.1 113.5 5.30 3.8
85 8.25 1.9 4.4 850 32.6 24.1 2.13 39.8 15.3 2.8 48.5 2.74 39.1 122.8 5.19 4.3
85 8.25 1.9 4.4 1000 33.2 25.8 2.17 40.6 15.3 2.9 49.2 2.63 40.2 115.6 5.48 3.8
85 11.00 3.1 7.2 850 33.2 24.3 2.07 40.1 16.0 2.5 49.6 2.76 40.2 124.0 5.27 4.3
85 11.00 3.1 7.2 1000 33.8 26.0 2.11 40.9 16.0 2.6 50.3 2.65 41.3 116.6 5.56 3.7
90 5.50 0.7 1.6 850 30.0 23.2 2.40 38.2 12.5 3.3 48.2 2.76 38.8 122.5 5.12 4.5
90 5.50 0.7 1.6 1000 30.6 24.8 2.44 38.9 12.5 3.4 48.9 2.65 39.9 115.3 5.41 3.9
90 8.25 1.8 4.2 850 31.2 23.6 2.26 39.0 13.8 3.0 50.4 2.81 40.8 124.9 5.26 4.4
90 8.25 1.8 4.2 1000 31.8 25.3 2.30 39.7 13.8 3.1 51.1 2.69 41.9 117.3 5.57 3.9
90 11.00 3.1 7.2 850 31.8 23.9 2.19 39.3 14.5 2.7 51.5 2.83 41.9 126.1 5.33 4.4
90 11.00 3.1 7.2 1000 32.4 25.6 2.23 40.1 14.5 2.8 52.2 2.71 43.0 118.3 5.65 3.8
100 5.50 0.7 1.6 850 27.4 22.2 2.69 36.6 10.2 3.8 0 0 0 0 0 0
100 5.50 0.7 1.6 1000 27.9 23.8 2.74 37.3 10.2 3.9 0 0 0 0 0 0
100 8.25 1.8 4.2 850 28.5 22.7 2.53 37.2 11.3 3.5 0 0 0 0 0 0
100 8.25 1.8 4.2 1000 29.1 24.3 2.58 37.9 11.3 3.5 0 0 0 0 0 0
100 11.00 3.0 6.9 850 29.1 22.9 2.46 37.6 11.8 3.1 0 0 0 0 0 0
100 11.00 3.0 6.9 1000 29.7 24.5 2.51 38.3 11.8 3.2 0 0 0 0 0 0
110 5.50 0.6 1.4 850 25.0 21.5 3.01 35.3 8.3 4.3 0 0 0 0 0 0
110 5.50 0.6 1.4 1000 25.5 23.0 3.07 36.0 8.3 4.3 0 0 0 0 0 0
110 8.25 1.7 3.9 850 26.0 21.9 2.86 35.7 9.1 3.9 0 0 0 0 0 0
110 8.25 1.7 3.9 1000 26.5 23.4 2.91 36.4 9.1 3.9 0 0 0 0 0 0
110 11.00 2.8 6.5 850 26.5 22.1 2.77 36.0 9.6 3.5 0 0 0 0 0 0
110 11.00 2.8 6.5 1000 27.0 23.6 2.82 36.7 9.6 3.5 0 0 0 0 0 0
120 5.50 0.6 1.4 850 23.2 21.3 3.40 34.7 6.8 4.7 0 0 0 0 0 0
120 5.50 0.6 1.4 1000 23.6 22.8 3.46 35.4 6.8 4.8 0 0 0 0 0 0
120 8.25 1.7 3.9 850 23.8 21.3 3.21 34.8 7.4 4.2 0 0 0 0 0 0
120 8.25 1.7 3.9 1000 24.3 22.8 3.27 35.5 7.4 4.3 0 0 0 0 0 0
120 11.00 2.7 6.2 850 24.2 21.4 3.12 34.9 7.8 3.8 0 0 0 0 0 0
120 11.00 2.7 6.2 1000 24.7 22.9 3.18 35.6 7.8 3.9 0 0 0 0 0 0
EWT
°F
GPM
WPD Cooling - EAT 80/67°F Heating - EAT 70°F
PSI FT
Airfl ow
CFM
TC SC kW HR EER HWC HC kW HE LAT COP HWC
20 Operation not recommended
30
40
50
60
70
80
85
90
100
Operation not recommended 110
120
Performance capacities shown in thousands of Btuh
Interpolation is permissible; extrapolation is not.
All entering air conditions are 80°F DB and 67°F WB in cooling, and 70°F DB in heating. ARI/ISO certifi ed conditions are 80.6°F DB and 66.2°F
WB in cooling and 68°F DB in heating.
Table does not refl ect fan or pump power corrections for ARI/ISO conditions.
All performance is based upon the lower voltage of dual voltage rated units.
Operation below 40°F EWT is based upon a 15% antifreeze solution.
Operation below 60°F EWT requires optional insulated water/refrigerant circuit (standard on residential models).
See performance correction tables for operating conditions other than those listed above.
“-” HWG operation is limited by a discharge temperature switch.
1000 CFM Nominal (Rated) Airfl ow Cooling, 1000 CFM Nominal (Rated) Airfl ow Heating
