GT-PX
24 Carrier Indoor & Outdoor Split Geothermal Heat Pumps - Rev.: 08/10/05
50YDS049 Full Load With FV4006
20 12.00 4.8 11.1 1400 0 0 0 0 0 0 31.8 2.89 22.2 91.0 3.22 3.8
20 12.00 4.8 11.1 1650 0 0 0 0 0 0 32.3 2.80 22.8 88.1 3.38 3.3
30 6.00 1.3 3.0 1400 55.8 35.9 2.23 62.5 25.0 - 34.7 3.00 24.7 92.9 3.39 4.0
30 6.00 1.3 3.0 1650 56.8 38.6 2.36 64.8 24.1 - 35.2 2.91 25.4 89.8 3.55 3.5
30 9.00 2.7 6.2 1400 56.2 36.0 2.11 62.5 26.6 - 36.3 3.04 26.1 94.0 3.50 3.9
30 9.00 2.7 6.2 1650 57.2 38.7 2.23 64.8 25.7 - 36.8 2.95 26.8 90.7 3.66 3.4
30 12.00 4.6 10.6 1400 56.6 36.0 2.03 62.6 27.9 - 37.2 3.07 26.9 94.6 3.55 3.9
30 12.00 4.6 10.6 1650 57.6 38.7 2.15 64.9 26.8 - 37.7 2.97 27.6 91.2 3.72 3.3
40 6.00 1.1 2.5 1400 55.5 37.2 2.43 63.0 22.8 - 39.8 3.17 29.2 96.3 3.68 4.1
40 6.00 1.1 2.5 1650 56.5 40.0 2.57 65.3 22.0 - 40.4 3.07 30.0 92.7 3.86 3.6
40 9.00 2.6 6.0 1400 56.1 37.2 2.30 63.0 24.4 - 41.8 3.22 31.0 97.6 3.80 4.0
40 9.00 2.6 6.0 1650 57.1 40.0 2.43 65.3 23.5 - 42.4 3.12 31.8 93.8 3.98 3.5
40 12.00 4.4 10.2 1400 56.3 37.3 2.23 63.0 25.2 - 42.9 3.25 32.0 98.4 3.87 4.0
40 12.00 4.4 10.2 1650 57.3 40.1 2.36 65.3 24.3 - 43.5 3.15 32.8 94.4 4.05 3.4
50 6.00 1.1 2.5 1400 54.2 37.8 2.63 62.4 20.6 1.9 45.1 3.33 33.9 99.8 3.97 4.3
50 6.00 1.1 2.5 1650 55.2 40.6 2.78 64.7 19.9 2.0 45.8 3.23 34.8 95.7 4.16 3.7
50 9.00 2.5 5.8 1400 55.3 37.9 2.49 63.0 22.2 1.7 47.5 3.40 36.0 101.4 4.09 4.2
50 9.00 2.5 5.8 1650 56.3 40.8 2.63 65.3 21.4 1.7 48.2 3.29 37.0 97.0 4.29 3.7
50 12.00 4.2 9.7 1400 55.7 37.9 2.42 63.1 23.0 1.4 48.9 3.44 37.3 102.3 4.17 4.2
50 12.00 4.2 9.7 1650 56.7 40.8 2.56 65.4 22.1 1.4 49.6 3.33 38.3 97.8 4.37 3.6
60 6.00 1.0 2.3 1400 52.2 37.3 2.84 61.2 18.4 2.8 50.9 3.51 39.0 103.7 4.25 4.6
60 6.00 1.0 2.3 1650 53.1 40.1 3.00 63.4 17.7 2.8 51.6 3.40 40.0 99.0 4.45 4.0
60 9.00 2.4 5.5 1400 53.7 37.8 2.69 62.1 20.0 2.4 53.7 3.59 41.5 105.5 4.38 4.5
60 9.00 2.4 5.5 1650 54.7 40.7 2.84 64.4 19.3 2.4 54.5 3.48 42.6 100.6 4.59 3.9
60 12.00 4.0 9.2 1400 54.3 38.0 2.62 62.5 20.7 2.0 55.3 3.63 43.0 106.6 4.46 4.5
60 12.00 4.0 9.2 1650 55.3 40.9 2.77 64.8 20.0 2.0 56.1 3.52 44.1 101.5 4.67 3.9
70 6.00 0.9 2.1 1400 49.7 36.5 3.08 59.4 16.1 3.8 56.7 3.70 44.1 107.5 4.49 5.0
70 6.00 0.9 2.1 1650 50.6 39.3 3.25 61.6 15.6 3.8 57.5 3.59 45.3 102.3 4.69 4.4
70 9.00 2.3 5.3 1400 51.5 37.3 2.91 60.7 17.7 3.2 60.0 3.80 47.1 109.7 4.63 5.0
70 9.00 2.3 5.3 1650 52.4 40.1 3.08 62.9 17.0 3.3 60.9 3.68 48.3 104.2 4.85 4.3
70 12.00 3.8 8.8 1400 52.4 37.7 2.83 61.2 18.5 2.7 61.8 3.86 48.7 110.9 4.69 4.9
70 12.00 3.8 8.8 1650 53.3 40.5 2.99 63.4 17.8 2.7 62.7 3.74 50.0 105.2 4.91 4.2
80 6.00 0.9 2.1 1400 46.9 35.5 3.34 57.6 14.0 4.9 62.7 3.91 49.3 111.5 4.70 5.6
80 6.00 0.9 2.1 1650 47.7 38.2 3.53 59.7 13.5 5.0 63.6 3.79 50.6 105.7 4.92 4.8
80 9.00 2.3 5.3 1400 48.7 36.4 3.16 58.9 15.4 4.2 66.4 4.02 52.6 113.9 4.84 5.5
80 9.00 2.3 5.3 1650 49.6 39.1 3.34 61.0 14.9 4.3 67.4 3.90 54.0 107.8 5.07 4.8
80 12.00 3.6 8.3 1400 49.7 36.8 3.07 59.5 16.2 3.5 68.5 4.10 54.5 115.3 4.90 5.4
80 12.00 3.6 8.3 1650 50.6 39.6 3.24 61.7 15.6 3.5 69.5 3.97 55.9 109.0 5.13 4.7
85 6.00 0.9 2.1 1400 45.3 34.8 3.49 56.6 13.0 5.6 65.6 4.02 51.9 113.4 4.78 5.9
85 6.00 0.9 2.1 1650 46.1 37.4 3.69 58.7 12.5 6.3 66.6 3.90 53.3 107.4 5.00 5.1
85 9.00 2.2 5.1 1400 47.3 35.6 3.30 57.9 14.3 4.8 69.6 4.16 55.4 116.0 4.90 5.8
85 9.00 2.2 5.1 1650 48.1 38.3 3.49 60.0 13.8 4.9 70.6 4.03 56.9 109.6 5.13 5.1
85 12.00 3.6 8.3 1400 48.2 36.1 3.21 58.6 15.0 3.9 71.7 4.23 57.3 117.4 4.97 5.4
85 12.00 3.6 8.3 1650 49.1 38.8 3.39 60.7 14.5 4.0 72.8 4.10 58.8 110.9 5.20 5.0
90 6.00 0.9 2.1 1400 43.7 34.0 3.64 55.7 12.0 6.2 68.7 4.14 54.6 115.4 4.86 6.2
90 6.00 0.9 2.1 1650 44.5 36.6 3.85 57.7 11.6 6.3 69.7 4.01 56.0 109.1 5.09 5.4
90 9.00 2.2 5.1 1400 45.8 34.9 3.44 56.9 13.3 5.3 72.8 4.28 58.2 118.1 4.99 6.1
90 9.00 2.2 5.1 1650 46.6 37.5 3.63 59.0 12.8 5.4 73.9 4.15 59.7 111.5 5.22 5.3
90 12.00 3.5 8.1 1400 46.8 35.3 3.34 57.6 14.0 4.3 75.1 4.37 60.1 119.7 5.04 6.0
90 12.00 3.5 8.1 1650 47.6 38.0 3.53 59.7 13.5 4.4 76.2 4.23 61.7 112.8 5.28 5.2
100 6.00 0.8 1.8 1400 40.7 32.8 3.99 53.8 10.2 7.6 0 0 0 0 0 0
100 6.00 0.8 1.8 1650 41.4 35.3 4.22 55.8 9.8 7.8 0 0 0 0 0 0
100 9.00 2.1 4.9 1400 42.6 33.6 3.77 54.9 11.3 6.5 0 0 0 0 0 0
100 9.00 2.1 4.9 1650 43.4 36.1 3.98 56.9 10.9 6.6 0 0 0 0 0 0
100 12.00 3.3 7.6 1400 43.6 33.9 3.66 55.6 11.9 5.3 0 0 0 0 0 0
100 12.00 3.3 7.6 1650 44.4 36.5 3.87 57.6 11.5 5.4 0 0 0 0 0 0
110 6.00 0.8 1.8 1400 37.6 31.8 4.40 52.3 8.5 9.2 0 0 0 0 0 0
110 6.00 0.8 1.8 1650 38.3 34.2 4.65 54.2 8.2 9.4 0 0 0 0 0 0
110 9.00 2.0 4.6 1400 39.4 32.4 4.15 53.2 9.5 7.8 0 0 0 0 0 0
110 9.00 2.0 4.6 1650 40.1 34.8 4.38 55.1 9.2 7.9 0 0 0 0 0 0
110 12.00 3.2 7.4 1400 40.4 32.7 4.02 53.7 10.0 6.4 0 0 0 0 0 0
110 12.00 3.2 7.4 1650 41.1 35.2 4.25 55.6 9.7 6.5 0 0 0 0 0 0
120 6.00 0.8 1.8 1400 34.8 31.2 4.88 51.1 7.1 10.9 0 0 0 0 0 0
120 6.00 0.8 1.8 1650 35.4 33.5 5.16 53.0 6.9 11.1 0 0 0 0 0 0
120 9.00 2.0 4.6 1400 36.4 31.4 4.59 51.7 7.9 9.3 0 0 0 0 0 0
120 9.00 2.0 4.6 1650 37.0 33.8 4.85 53.6 7.6 9.4 0 0 0 0 0 0
120 12.00 3.0 6.9 1400 37.2 31.7 4.46 52.1 8.3 7.6 0 0 0 0 0 0
120 12.00 3.0 6.9 1650 37.9 34.1 4.71 54.0 8.0 7.7 0 0 0 0 0 0
EWT
°F
GPM
WPD Cooling - EAT 80/67°F Heating - EAT 70°F
PSI FT
Airfl ow
CFM
TC SC kW HR EER HWC HC kW HE LAT COP HWC
20 Operation not recommended
30
40
50
60
70
80
85
90
100
Operation not recommended 110
120
Performance capacities shown in thousands of Btuh
Interpolation is permissible; extrapolation is not.
All entering air conditions are 80°F DB and 67°F WB in cooling, and 70°F DB in heating. ARI/ISO certifi ed conditions are 80.6°F DB and 66.2°F
WB in cooling and 68°F DB in heating.
Table does not refl ect fan or pump power corrections for ARI/ISO conditions.
All performance is based upon the lower voltage of dual voltage rated units.
Operation below 40°F EWT is based upon a 15% antifreeze solution.
Operation below 60°F EWT requires optional insulated water/refrigerant circuit (standard on residential models).
See performance correction tables for operating conditions other than those listed above.
“-” HWG operation is limited by a discharge temperature switch.
1650 CFM Nominal (Rated) Airfl ow Cooling, 1650 CFM Nominal (Rated) Airfl ow Heating
