15
DIRECTIONS
FOR
USE
DIRECTIONS FOR USE
For a totally comfortable and relaxed patient, add a Lowered Arm Rest Shelf
to your lift table. It’s covered in the same luxurious plush padding as the
table itself. The Lowered Arm Rest Shelf can be removed when not in use and
stored away. It can also act as a table extender, when used in place of the face
rest or at the foot of the table. For complete use & care instructions see product
instructions “Arm rest shelf instructions” included with the arm rest.
Lowered Arm Rest Shelf with
Aromatherapy, shown here with
QuickLock™ Face Rest
Lowered Arm Rest Shelf, shown here
used as a table extender
Do Not extend the dowels
of the Face Rest further than
3” from the table outlets to
ensure a stable connection.
* U.S. Patent #5,177,823
CAUTION
Do not put excessive weight
or pressure on the face rest.
QuickLock™ Face Rest
Important Safety Note: Maximum
Distance from edge of Table = 3”
CAUTION
Do not sit on or put excessive
weight or pressure on lowered
arm shelf.
LOWERED ARM REST INSTRUCTIONS
QUICKLOCK™ FACE REST INSTRUCTIONS
Double articulating action provides nearly limitless positioning options
with the QuickLock ™ Face Rest. The adjustable pad takes pressure off
sensitive facial areas while providing superb support. The QuickLock ™
Face Rest can be used in both prone and supine positioning and folds
out of the way when not in use. Adjustments are made easily by loosening
the cam locks, adjusting for height and angle and then locking the cam
locks into that position.
To remove the QuickLock
™ Face Rest, just pull the frame from the outlets in
the end of the table until it comes free. When replacing the QuickLock ™
Face Rest, just push the frame back into the outlets being sure to keep the
dowels within 3” of the table to ensure a stable connection. For complete use
& care instructions see product instructions “QuickLock Face Rest instructions”
included with the face rest.
