7. Settings
-91-
7.5.6 MPPS tab
This screen is displayed when the MPPS tab is clicked.
MPPS tab
1 Set the communication parameters.
2 Check the connections with the server.
Click [Connection Check...].
If the connections have been made properly, the Information screen is displayed.
When [OK] is clicked, the Information screen is closed.
Information screen
Item Operation
Server AE Title
Input the title using not more than 16 characters. (Required)
The backslash (\) cannot be input.
Host Name Input no more than 32 characters for the IP address or host name. (Required)
Port No. Input a number from 0 to 65535 as the port number. (Required)
When the Warning screen is displayed
Check out the following when the Warning screen is displayed.
• Is the network operating properly?
• Is the server working properly?
