Canon CR-1 MARK II - Manual (Page 59)

6. Main screen operations
-51-
6.3.4 Enlarging an area of the image (Loupe)
A part of an image can be enlarged for display.
1 Select the image.
Click the thumbnail image.
2 Enlarge a part of an image for display.
Click the Loupe icon, and then click over the main image with the mouse.
To move the enlargement position, move the mouse while holding down the left-mouse button.
To restore to the original image, release the left-mouse button.
To return to the original pointer, click the Hand icon.
Enlarged display
6.3.5 Moving the displayed area
The displayed area of an enlarged image can be moved in the main image.
1 Click the Hand icon.
2 Move the mouse over the main image that is being enlarged while holding down the left-
mouse button.
Enlargement display size and magnification rate
The displayed size and magnification rate are determined by the settings on the Loupe tab. See
7.9.5 Loupe tab (see page 106) for details.
