Spectrum2 Printer Operator’s Guide
Document Revision: 102803
28
Installing Print Ribbon
The Ribbon Installation procedure is easiest to perform with the CD tray open. It is
recommended that the Spectrum2 be turned OFF during ribbon installation.
General information
• The Spectrum2 uses ribbon rollers to hold the supply ribbon (ribbon rolled on tube)
and the take up core (empty cardboard tube).
• The supply ribbon is put on a silver roller and the take up core is placed on a gray
(geared) roller
• The supply ribbon roller is placed in slots in the front of the printer
• The take-up core is placed in slots in central area of the printer
• The ribbon is threaded around the chassis and attached to the take up core using the
adhesive strip on the end of the ribbon (or adhesive tape).
• After the rollers are placed in the Printer Chassis, the chassis must be opened to
thread ribbon through the printer
• Open Printer Chassis by unscrewing the Chassis Lock Knob
• Lift Printer Chassis upward
• When printer ribbon is installed, close chassis gently and screw the Chassis Lock
Knob back into place.
• Try to lift the chassis upwards to confirm that it is locked, and secure.
• Ribbon is now installed and the printer is ready for printing CD Labels
• Please see Printer Ribbon Installation Chart for more details.
