MF Digital Spectrum 2 Thermal Installation Guide User Manual
Minimum pc system requirements
Scribe EC with Spectrum 2 Printer
Installation Guide
Document Revision: 2/21
SCRIBE EC WITH SPECTRUM 2 PRINTER INSTALLATION GUIDE
Minimum PC System Requirements
•
A Pentium II/III PC 800 MHz or faster
•
Windows 2000 Pro (Service Pack 4.0) or Windows XP
•
512 MB Ram
•
7200 RPM ATA-100 Clean Hard Disk NTFS - (5GB Free Space)
•
800 x 600 display, 16-bit color recommended
•
Two Button Mouse
•
Two Free PCI Slots
•
1 external COM port (COM1 or COM2) - 2 ports needed if using Prism
Plus or Spectrum2
•
Win ASPI driver layer (Included)
•
IEEE-1394s adapters (Included) (Except print Station)
•
Appropriate IEEE-1284 Printer Cable if attached
MF DIGITAL
121 Carolyn Blvd.
Farmingdale, NY 11735
001 631 249 9393
Table of contents
Document Outline
- SCRIBE EC WITH SPECTRUM 2 PRINTER INSTALLATION GUIDE
- Minimum PC System Requirements
- IF YOU PURCHASED A PRINT STATION – SKIP THIS PAGE
- Installing the Firewire Adapter Card
- Installing the Drive Bay
- Preparing the Spectrum 2 Printer
- Making the Connection
- 1 & 2 Drive Systems4 Drive System
- Installing the SCRIBE EC Software
- Installing the SCRIBE EC Alignment Utility Installing the Spectrum 2 Printer Driver
- Installing the Spectrum 2 Printer Driver (cont.)
- Adjusting the Spectrum 2 Printer Driver Settings
- Aligning the Drive Tower
- Aligning the Spectrum 2 Printer
