71M653X Software User’s Guide
Opcode Mnemonic Opcode Mnemonic Opcode Mnemonic
0x60 JZ rel 0x80 SJMP rel 0xA0 ORL C,bit
0x61 AJMP addr11 0x81 AJMP addr11 0xA1 AJMP addr11
0x62 XRL direct,A 0x82 ANL C,bit 0xA2 MOV C,bit
0x63 XRL direct,#data 0x83 MOVC A,@A+PC 0xA3 INC DPTR
0x64 XRL A,#data 0x84 DIV AB 0xA4 MUL AB
0x65 XRL A,direct 0x85 MOV direct,direct 0xA5 Reserved
0x66 XRL A,@R0 0x86 MOV direct,@R0 0xA6 MOV @R0,direct
0x67 XRL A,@R1 0x87 MOV direct,@R1 0xA7 MOV @R1,direct
0x68 XRL A,R0 0x88 MOV direct,R0 0xA8 MOV R0,direct
0x69 XRL A,R1 0x89 MOV direct,R1 0xA9 MOV R1,direct
0x6A XRL A,R2 0x8A MOV direct,R2 0xAA MOV R2,direct
0x6B XRL A,R3 0x8B MOV direct,R3 0xAB MOV R3,direct
0x6C XRL A,R4 0x8C MOV direct,R4 0xAC MOV R4,direct
0x6D XRL A,R5 0x8D MOV direct,R5 0xAD MOV R5,direct
0x6E XRL A,R6 0x8E MOV direct,R6 0xAE MOV R6,direct
0x6F XRL A,R7 0x8F MOV direct,R7 0xAF MOV R7,direct
0x70 JNZ rel 0x90 MOV
DPTR,#data16
0xB0 ANL C,bit
0x71 ACALL addr11 0x91 ACALL addr11 0xB1 ACALL addr11
0x72 ORL C,direct 0x92 MOV bit,C 0xB2 CPL bit
0x73 JMP @A+DPTR 0x93 MOVC
A,@A+DPTR
0xB3 CPL C
0x74 MOV A,#data 0x94 SUBB A,#data 0xB4 CJNE A,#data,rel
0x75 MOV direct,#data 0x95 SUBB A,direct 0xB5 CJNE A,direct,rel
0x76 MOV @R0,#data 0x96 SUBB A,@R0 0xB6 CJNE @R0,#data,rel
0x77 MOV @R1,#data 0x97 SUBB A,@R1 0xB7 CJNE @R1,#data,rel
0x78 MOV R0.#data 0x98 SUBB A,R0 0xB8 CJNE R0,#data,rel
0x79 MOV R1.#data 0x99 SUBB A,R1 0xB9 CJNE R1,#data,rel
0x7A MOV R2.#data 0x9A SUBB A,R2 0xBA CJNE R2,#data,rel
0x7B MOV R3.#data 0x9B SUBB A,R3 0xBB CJNE R3,#data,rel
0x7C MOV R4.#data 0x9C SUBB A,R4 0xBC CJNE R4,#data,rel
0x7D MOV R5.#data 0x9D SUBB A,R5 0xBD CJNE R5,#data,rel
0x7E MOV R6.#data 0x9E SUBB A,R6 0xBE CJNE R6,#data,rel
0x7F MOV R7.#data 0x9F SUBB A,R7 0xBF CJNE R7,#data,rel
Table 6-9: Instruction Set in Hexadecimal Order
