78Q8430 Software Driver Development Guidelines UG_8430_004
Rule# Previous
Hit Match Previous
Hit Mask Data
Match Data
Mask Match
Control Byte
Offset Action Inter-
rupt
Comment
Process source address. Negative filter on multicast.
0x2F 0x30 0x70 0x01 0x01 DROP 0x00 NOP 0 MC drop
0x2E 0x30 0x70 0x00 0x00 MD 0x05 NOP 0 pass other
Process Len/Type field, MAC control frames and start IP header checksum check.
0x2D 0x2B 0x7F 0x00 0xFF MD 0x02 VLAN 0
0x2C 0x00 0x00 0x00 0x00 DONE 0x00 NOP 0
0x2B 0x2E 0x7F 0x81 0xFF MD 0x00 TDLTH 0
0x2A 0x2B 0x7F 0x00 0x00 DONE 0x00 TDLTL 0
0x29 0x2F 0x7C 0x88 0xFF MD 0x00 TDLTH 0
0x28 0x29 0x7F 0x08 0xFF MD 0x00 MCTL 0
0x27 0x29 0x7F 0x00 0x00 DONE 0x00 TDLTL 0
0x26 0x2F 0x7C 0x00 0x00 MD 0x00 TDLTH 0
0x25 0x26 0x7F 0x00 0x00 MD 0x00 TDLTL 0
0x24 0x25 0x7F 0x40 0xF0 MD 0x00 IPCK 0
0x23 0x24 0x7E 0x00 0x00 MD 0x3F TXA 0
0x22 0x28 0x7F 0x00 0xFF MD 0x00 NOP 0
0x21 0x28 0x7F 0x00 0x00 DONE 0x00 NOP 0
0x20 0x22 0x7F 0x01 0xFF MD 0x00 NOP 0 MCTL pause
0x1F 0x22 0x7F 0x00 0x00 DONE 0x00 NOP 0 MCTL other
0x1E 0x20 0x7F 0x00 0x00 MD 0x00 TDPH 0
0x1D 0x1E 0x7F 0x00 0x00 MX 0x00 TDPL 0
0x1C 0x1D 0x7F 0x3D 0xFF DONE 0x00 PAUSE 0
0x1B 0x1D 0x7F 0x00 0x00 DONE 0x00 NOP 0 MCTL pause
with bad
SRC
0x1A 0x00 0x00 0x00 0x00 DONE 0x00 NOP 0
0x19 0x00 0x00 0x00 0x00 DONE 0x00 NOP 0
0x18 0x00 0x00 0x00 0x00 DONE 0x00 NOP 0
0x17 0x00 0x00 0x00 0x00 DONE 0x00 NOP 0
0x16 0x00 0x00 0x00 0x00 DONE 0x00 NOP 0
OnNow
This section identifies the OnNow example from the 78Q8430 Data Sheet which is based on an
example taken from the Microsoft OnNow specification. Actual OnNow is likely to be more complex.
0x15 0x23 0x7F 0x54 0xFF MD 0x00 NOP 0
0x14 0x15 0x7F 0x00 0x00 MD 0x02 NOP 0
0x13 0x14 0x7F 0x04 0xFF MD 0x00 NOP 0
0x12 0x13 0x7F 0x05 0xFF MD 0x00 NOP 0
0x11 0x12 0x7F 0x06 0xFF MD 0x00 NOP 0
0x10 0x11 0x7F 0x07 0xFF DONE 0x00 WAKE 0
