78Q8430 Software Driver Development Guidelines UG_8430_004
Appendix A – Default CAM Rule Summary
Table 9: Default CAM Rules
Rule# Previous
Hit Match Previous
Hit Mask Data
Match Data
Mask Match
Control Byte
Offset Action Inter-
rupt
Comment
0x7F 0x00 0x7F 0xFF 0xFF MD 0x00 NOP 0
0x7E 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x7D 0x00 0x7F 0x01 0xFF MD 0x00 SETMC 0
0x7C 0x00 0x7F 0x01 0x01 MD 0x00 SETMC 0
0x7B 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x7A 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x79 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x78 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x77 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x76 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x75 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x74 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x73 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x72 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x71 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x70 0x00 0x7F 0x00 0x00 MD 0x00 NOP 0
0x6F 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x6E 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x6D 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x6C 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x6B 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x6A 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x69 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x68 0x70 0x78 0x00 0x00 MD 0x00 NOP 0
0x67 0x7F 0x7F 0xFF 0xFF MD 0x00 NOP 0
0x66 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x65 0x7D 0x7F 0x80 0xFF MD 0x00 NOP 0
0x64 0x7C 0x7C 0x00 0x00 MD 0x00 NOP 0
0x63 0x67 0x7F 0xFF 0xFF MD 0x00 NOP 0
0x62 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x61 0x65 0x7F 0xC2 0xFF MD 0x00 NOP 0
0x60 0x64 0x7C 0x00 0x00 MD 0x00 NOP 0
0x5F 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x5E 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x5D 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x5C 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x5B 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x5A 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
0x59 0x00 0x00 0x00 0x00 MD 0x00 NOP 0
48 Rev. 1.0
