ENGLISH
Chapter 4: Using the DVR
DVR User’s Manual
43
4.4.4 Setting Up Mobile Devices
To remotely access the DVR via mobile devices, be sure that the DVR network connection is properly configured before
proceeding with the mobile devices setup.
To configure the mobile devices, do the following:
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DEVICE > MOBILE.
3
Set the User Name and User Password which you have set for the DVR (see “3.3.2 Virtual Keyboard” on page 19
for details on using the virtual keyboard).
4
Enter the Server Port. The setting range is between 1024 and 65535.
Note:
• The user name and password cannot be left empty.
• To forward a server port to the router, see
“4.2.4 Port Forwarding” on page 33 .
5
After all settings are complete, click Apply.
6
When data saving is complete, click OK.
Note:
For details on supported mobiles, see “DVR SHA Series Support Manual” in the enclosed CD.
4.4.5 Setting Motion Detection
For added security, enable the motion detection feature. When motion is detected on a selected area, the DVR issues
an alarm notification.
To configure motion detection, do the following:
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DEVICE > MOTION.
3
In Channel, select the channel to activate motion detection.
