ENGLISH
Chapter 2: Installation
16
DVR User’s Manual
2.6 Connecting to Other Devices
You can connect other devices such as mouse, speaker, or microphone to the DVR. Connect them via their respective
cable(s) into the corresponding connectors on the back of the DVR.
• Mouse: Plug into the USB connector.
• Speaker: Plug into the audio output connectors.
• Microphone: Plug into the audio input connectors.
TX+ TX-
1
2
3
4
1
2
VIDEO
INPUT
VIDEO OUTPUT
7
8
5
6
VIDEO
INPUT
2
1
2
1
4
3
AUDIO
INPUT AUDIO OUTPUT
VGA
DC 12V LAN
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK. DO NOT OPEN COVERS. NO USER
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
WARNING: TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE UNITS NOT SPECIFICALLY DESIGNED
FOR OUTDOOR USE TO RAIN OR MOISTURE.
2
1
2
1
4
3
AUDIO
INPUT
AUDIO
OUTPUT
Mouse Speaker
Microphone
