ENGLISH
Chapter 2: Installation
12
DVR User’s Manual
Chapter 2: Installation
2.1 Installing the Hard Disk Drive
Depending on the package you have purchased, the hard disk drive may be included in the full package. If it is not pre-
installed, follow the steps below to install the hard disk drive.
You can install a 3.5” SATA hard disk drive into your DVR. Be sure to remove the power adapter before installing the
hard disk drive.
DO NOT install or remove hard disk drive while the device power is turned on.
1
Loosen the screws in the left, right, and rear sides as
shown.
2
Push back then lift up the cover to remove it.
3
Connect the data and power cables to the hard disk
drive (HDD).
4
Attach the HDD to the bracket using 2 screws.
5
Attach the cover and the screws back in place.
