Chapter 3: VLAN Configuration

3-38

802.1Q VLAN User’s Guide

15.

On the 802.1Q VLAN Main Menu screen, use the arrow keys to
highlight the DEVICE VLAN CONFIGURATION menu item.
Press ENTER. The Device VLAN Configuration screen,

Figure 3-14

,

displays.

Figure 3-14

Walkthrough Stage Four

16.

Use the arrow keys to highlight the Admin Status field of
VLAN ID 2, the TEST VLAN.

17.

Press the SPACE bar to toggle the field to display Enabled.

18.

Use the arrow keys to highlight the SAVE command at the bottom of
the screen.

19.

Press ENTER. The message “SAVED OK” displays. The switch
activates the new VLAN.

This effectively completes the configuration of a single VLAN, assigning
it to a port, and configuring the switch to forward the frames received on
that port to be forwarded with the VLAN information included in the
frame.

Firmware Revision: XX.XX.XX

Device/VLAN Configuration

25993-12

Module Type: xxxxx-xx

BOOTPROM Revision: XX.XX.XX

6C105 LOCAL MANAGEMENT

Slot Number: xx

RETURN

EXIT

Forward Default VLAN Out All Ports: [NO]

VLAN ID

1

2

FID

1

2

VLAN Name

DEFAULT VLAN

TEST VLAN

Admin Status

[Enabled]

[Enabled]

VLAN ID: 1 FID: 2 VLAN Name: DEFAULT VLAN [ADD]

SAVE
