Chapter 3: VLAN Configuration
3-14 802.1Q VLAN User’s Guide
3.5 PORT ASSIGNMENT CONFIGURATION SCREEN
When to Use
To select a mode of operation for each port and to assign a Port VLAN
Identification (PVID) to each port.
How to Access
Use the arrow keys to highlight the PORT ASSIGNMENT
CONFIGURATION menu item on the 802.1Q VLAN Configuration
Menu screen and press ENTER. The Port Assignment Configuration
screen displays.
Screen Example
Figure 3-6 Port Assignment Configuration Screen
Firmware Revision: XX.XX.XX
Port Assignment Configuration
25992-06
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
RETURN EXIT
Port
1
2
3
4
5
6
7
8
9
10
11
12
Port Mode
[1D TRUNK]
[1Q TRUNK]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
VLAN Name
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
SAVE PREVIOUS NEXT
VLAN ID
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
FID
0001
0001
0001
0001
0001
0001
0001
0001
0001
0001
0001
0001
