Quick VLAN Walkthrough
802.1Q VLAN User’s Guide 3-37
13. Use the arrow keys to highlight the Port Mode field for port 10. Use
the SPACE bar or BACKSPACE key to step sequentially through the
possible settings of the port until 1Q TRUNK is displayed.
14. Use the arrow keys to highlight the SAVE command at the bottom of
the screen. Press ENTER. Port 10 is now acting as a 1Q Trunk port and
every VLAN is in its Port VLAN List. The frame format for every
VLAN is also set to tagged. The screen should now look like
Figure 3-13 .
Figure 3-13 Walkthrough Stage Three
Now that the TEST VLAN and the 1Q Trunk connection are set up, we
can proceed to activate the TEST VLAN.
Firmware Revision: XX.XX.XX
Port Assignment Configuration
25991-11
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
RETURN EXIT
Port
1
2
3
4
5
6
7
8
9
10
11
12
Port Mode
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[1Q TRUNK]
[HYBRID]
[HYBRID]
VLAN Name
DEFAULT VLAN
DEFAULT VLAN
TEST VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
DEFAULT VLAN
SAVE PREVIOUS NEXT
VLAN ID
[0001]
[0001]
[0002]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
