Device VLAN Configuration Screen
802.1Q VLAN User’s Guide 3-13
4. Press ENTER. The message “SAVED OK” displays.
3.4.7 Changing the Forwarding Mode
To change the forwarding mode of the switch, proceed as follows:
1. Use the arrow keys to highlight the Forward Default VLAN Out All
Ports field.
2. Press the SPACE bar or BACKSPACE to toggle between YES and
NO. The YES selection places the default VLAN (VLAN ID=1) in the
Port VLAN Lists of all ports on the switch. The NO selection removes
the default VLAN from the Port VLAN Lists of all ports, unless those
ports have a PVID of 1 (those belonging to only the Default VLAN).
3. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” displays.
3.4.8 Paging Through the VLAN List
To display additional VLANs that do not display in the current VLAN
List as shown on the screen, use the NEXT or PREVIOUS commands
located at the bottom of the screen, as follows:
1. To display the next screen, use the arrow keys to highlight NEXT.
Press ENTER to view the entries on the next screen.
2. To display the previous screen, use the arrow keys to highlight
PREVIOUS. Press ENTER to view the entries on the previous screen.
NOTE
The default VLAN cannot be disabled.
NOTE
The NEXT and PREVIOUS fields will only display if there are
further VLAN List entries to page through.
