Chapter 3: VLAN Configuration
3-18 802.1Q VLAN User’s Guide
How to Access
Use the arrow keys to highlight the PORT FILTERING
CONFIGURATION menu item on the 802.1Q VLAN Configuration
Menu screen and press ENTER. The Port Filtering Configuration screen
displays.
Screen Example
Figure 3-7 Port Filtering Configuration Screen
Firmware Revision: XX.XX.XX
Port Filtering Configuration
25992-07
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
RETURN EXIT
Filter Using VLAN Lists: [NO]
Filter All Untagged Frames: [NO]
VLAN ID
0001
0003
0004
0012
0014
0020
VLAN Name
Default VLAN
Not Defined
Not Defined
Not Defined
Not Defined
Not Defined
SAVE PREVIOUS NEXT
Port: [002]
Port VLAN List
