Protocol Ports Configuration Screen
802.1Q VLAN User’s Guide 3-31
3.9 PROTOCOL PORTS CONFIGURATION SCREEN
When to Use
To display the current ports and port types associated with a VLAN and
protocol selected in the Protocol VLAN Configuration screen described in
Section 3.8 .
How to Access
Use the arrow keys to highlight a line of information under the VLAN
ID/Protocol Type/Configured Ports BitMap columns in the Protocol
Priority Configuration screen and press ENTER. The Protocol Ports
Configuration
screen displays.
Screen Example
Figure 3-10 Protocol Ports Configuration Screen
NOTE
The line of information selected must have been saved before it
can be used to access the Protocol Ports Configuration screen
as described below.
Firmware Revision: XX.XX.XX
Protocol Ports Configuration
2599_24
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
Current Protocol Ports
15
30
Port Type
Ethernet
ATM PVC VCI-1 VPI-23
Protocol: 0X800
Port: [ 31] [ DELETE ALL PORTS ]
VLAN ID : 1
ATM PVC VCI-1 VPI-23
RETURN EXIT SAVE PREVIOUS NEXT
