Quick VLAN Walkthrough
802.1Q VLAN User’s Guide 3-35
Figure 3-11 Walkthrough Stage One
It is now time to assign a port to this new VLAN.
9. Use the arrow keys to highlight the RETURN command at the bottom
of the screen. Press ENTER. The 802.1Q VLAN Configuration Menu
screen displays. Use the arrow keys to select the PORT
ASSIGNMENT CONFIGURATION menu item and press ENTER.
The Port Assignment Configuration screen displays.
10. Use the arrow keys to highlight the VLAN ID field for the module and
port combination you wish to change.
NOTE
For the purposes of this walkthrough, port 3 will be configured.
NOTE
As this port will connect to a single workstation, and is not to be
used for switch-to-switch communications, it is not necessary
to change the PORT MODE from the default setting of
HYBRID
.
Firmware Revision: XX.XX.XX
Device/VLAN Configuration
25993-09
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
RETURN EXIT
Forward Default VLAN Out All Ports: [NO]
VLAN ID
1
2
FID
1
2
VLAN Name
DEFAULT VLAN
TEST VLAN
Admin Status
[Enabled]
[Disabled]
VLAN ID: 1 FID: 2 VLAN Name: TEST VLAN [ADD]
SAVE
