Chapter 3: VLAN Configuration
3-36 802.1Q VLAN User’s Guide
11. Use the SPACE bar to step sequentially through the previously
configured VLAN ID numbers. When the number 0002 (the new
VLAN ID) is displayed, the FID field updates to 0002, and the VLAN
Name field updates showing the name assigned to this VLAN, TEST
VLAN.
12. Use the arrow keys to highlight the SAVE command at the bottom of
the screen. Press ENTER. The PVID for Port 3 is now configured to
the TEST VLAN. The TEST VLAN is also added to the Port VLAN
List for Port 3 with a frame format of Untagged. The screen should
now look like
Figure 3-12 .
Figure 3-12 Walkthrough Stage Two
Now that port 3 belongs to the TEST VLAN, we will designate one port
as a 1Q Trunk port for a connection to another VLAN aware switch. This
1Q Trunk port will carry traffic from all VLANs, allowing VLAN frames
to maintain their VLAN ID across multiple switches.
NOTE
For the purposes of this walkthrough, port 10 will be configured
as the trunk port.
Firmware Revision: XX.XX.XX
Port Assignment Configuration
25992-10
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
RETURN EXIT
Port
1
2
3
4
5
6
7
8
9
10
11
12
Port Mode
[1D TRUNK]
[1Q TRUNK]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
[HYBRID]
VLAN Name
Default VLAN
Default VLAN
TEST VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
Default VLAN
SAVE PREVIOUS NEXT
VLAN ID
[0001]
[0001]
[0002]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
[0001]
FID
0001
0001
0002
0001
0001
0001
0001
0001
0001
0001
0001
0001
