VLAN Forwarding Configuration Screen
802.1Q VLAN User’s Guide 3-21
3.7 VLAN FORWARDING CONFIGURATION SCREEN
When to Use
To perform the following functions:
• View the ports included in a VLAN’s Forwarding List.
• Define which ports to include in the VLAN’s Forwarding List.
• Specify the formats of the frames (Tagged or Untagged) that a VLAN
port will forward.
How to Access
Use the arrow keys to highlight the VLAN FORWARDING
CONFIGURATION menu item on the 802.1Q VLAN Configuration
Menu screen and press ENTER. The VLAN Forwarding Configuration
screen displays.
Screen Example
Figure 3-8 VLAN Forwarding Configuration Screen
Firmware Revision: XX.XX.XX
VLAN Forwarding Configuration
25991-08
Module Type: xxxxx-xx
BOOTPROM Revision: XX.XX.XX
6C105 LOCAL MANAGEMENT
Slot Number: xx
RETURN EXIT
VLAN Name: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
ATM PVC VCI-1 VPI-23
Current VLAN Ports
Port 15
Port 17
Port 20
Port 23
Port 24
Port 25
Port 35
Port 30
Frame Format
Untagged
Untagged
Untagged
Untagged
Untagged
Untagged
Tagged
Untagged
SAVE PREVIOUS NEXT
VLAN ID: [4094]
Port Type
Etherent Frontpanel
Etherent Frontpanel
Etherent Frontpanel
Etherent Frontpanel
Etherent Frontpanel
Etherent Frontpanel
ATM ELAN Finance
ATM PVC VCI-1 VP!-23
Port: [30]
[DELETE]
Frame Type: [Untagged]
