802.1Q VLAN Configuration Menu Screen
802.1Q VLAN User’s Guide
3-7
Menu Definitions
Table 3-1
802.1Q VLAN Configuration Menu Screen Menu Items
Menu Item
Screen Function
DEVICE VLAN
CONFIGURATION
Used to view, add, name, enable, or disable VLANs
within the device, and also associate the VLANs to a
Filter Database ID (FID). It also enables the user to
configure attributes that apply to the entire switch and/or
VLANs. Refer to
for additional information.
PORT
ASSIGNMENT
CONFIGURATION
Displays a list of ports and enables the user to assign a
Port VLAN ID (PVID) to each port. The screen also allows
the user to change the operational mode of a port. Refer
to
for additional information.
PORT FILTERING
CONFIGURATION
Used to set the switch to filter out inbound frames to
prevent them from being forwarded by the switch out a
particular port. This screen also lists the VLANs whose
frames are eligible to be transmitted out that port. Refer
to
for additional information.
VLAN
FORWARDING
CONFIGURATION
Used to view which ports are included in the VLAN’s
Forwarding List and whether to include a Tag Header in a
frame being transmitted. Refer to
for
additional information.
PROTOCOL
VLAN
CONFIGURATION
Used to assign VLAN IDs to protocol types of received
frames and to access the Protocol Port Configuration
screen to add or delete transmitting ports associated with
a specific VLAN ID and protocol type. Refer to
for additional information.
