Connections
IMPORTANT!
If the picture is distorted, check the
Video Output settings Make sure it is set
to ‘S'Video*, see page 29.
Use the S-video cabJe (not supplied) to connect
the DVD system’s S-VI DEO OUT jack to the
S'"Video input jack (or labeled asY/C or S'VHS)
on the TV
To heartheTV channels through this DVD
system, use the audio cables (white/red) to
connect TV IN (UR) jacks to the
corresponding AUDIO OUT jacks on the TV,
Set the P-SCAN switch to 'OFF',
IMPORTANT!
- If yourTV only has a single Antenna In
jack (or labeled as 75 ohm or RF In), you
will need an RF modulator in order to
view the DVD playback on the TV. See
your electronics retailer or contact
Philips for details on RF modulator
availability and operations.
Use the composite video cable (yellow) to
connect the DVD system's CVBS jack to the
video input jack on the RF modulator
Use the RF coaxial cable (not supplied) to
connect the RF modulator to yourTV's RF jack.
Set the P-SCAN switch to 'OFF',
