CyberDome II
Installation Manual
42
Figure 32. Fastening the arm to the mounting surface
8. If needed, seal all mounting holes so that no moisture can leak into the mounting surface.
9. Push inside the arm or pull taut any looped cables that are extending out of the access area.
10. Reattach the cover (Figure 33).
Figure 33. Reattaching the access cover
11. Before you attach the housing to the arm, attach the housing safety cable to the arm safety chain
(Figure 34).
Note: The safety cable for rugged housings is metal and for plastic housings is a beaded cord.
a. Cut the quick tie on the safety chain.
b. Hold the housing near the arm’s collar.
c. Slide the ball of the safety cable into the clip of the safety chain.
d. Ensure that the safety chain and cable can bear the housing’s weight.
e. Lower the housing until the safety chain and cable are taut.
Note: Adhere to minimum load
requirements. See Table 1 on page 4.
