Speed Dome Camera Instruction Manual 40/57
‰
Auto Exposure Setup
AE SETUP - GLOBAL
------------------------
BACKLIGHT OFF
DAY/NIGHT
BRIGHTNESS 25
IRIS AUTO
SHUTTER ESC
AGC HIGH
SSNR MIDDLE
SENS-UP
BACK
EXIT
z Backlight [ON/OFF]
Sets Backlight Compensation to ON/OFF.
If a bright backlight is present, the
subjects in the picture may appear dark
or as a silhouette. Backlight
compensation enhances objects in the
center of the picture. The camera uses the
center of the picture to adjust the iris. If
there is a bright light source outside of
this area, it will wash out to white. The
camera will adjust the iris so that the
object in the sensitive area is properly
exposed.
z Day/Night [AUTO1/AUTO2/DAY/NIGHT]
Sets Day&Night mode. You can increase
sensitivity in low light conditions by
switching to black-white mode (removing
the IR cut filter or turning on DSS). Color
mode is preferred in normal lighting
conditions. The time to change a mode is
10 sec.
# AUTO1 Mode : The sensitivity to change
a mode is fixed.
# AUTO2 Mode : The sensitivity to change
Night mode to Day mode is adjustable.
The sensitivity range is 1~255. The higher
numeric value is selected, the lower
illumination Night mode changes to Day
mode at. If this is set to AUTO2 mode,
ACG is fixed to HIGH.
z Brightness [0~100]
Adjusts the brightness of the images. Iris,
The Shutter Speed and Gain are adjusted
automatically in correspondence with
each numeric value.
OSD MENU
4
