Display Setup
DISPLAY SETUP
------------------------
CAMERA ID ON
PTZ INFORMATION AUTO
ACTION TITLE AUTO
PRESET LABEL AUTO
ALARM I/O AUTO
BACK
EXIT
Display setup allows you to program how labels are
displayed on the monitor. In case of AUTO, the labels are
displayed on the monitor when there are any changes in
parameters.
z
Camera ID [ON/OFF]
Displays the selected Camera ID
(Address).
z PTZ Information [ON/OFF/AUTO]
Displays the amount of pan from zero
degree vertical, the amount of tilt from
zero degree horizontal and current
compass direction. Also identifies the
amount of the zoom magnification.
z Action Title [ON/OFF/AUTO]
Identfies Actions.
"SET PRESET xxx"
"PRESET xxx"
"PATTERN x"
"SWG/PRESET xxx"
"UNDEFINED"
z Preset Label [ON/OFF/AUTO]
Displays the preset labels when the
camera arrives at presets.
z Alarm I/O [ON/OFF/AUTO]
Displays the activated alarms. This
information shows the current state of
Alarm Inputs and Relay Outputs. If an
Input point is ON state, it will show a
number corresponding to each point. If
an Input point is OFF state, '-' will be
displayed.
Example) The point 2 & 3 of inputs are
ON and Output is ON, OSD will show as
below.
I:-23 O:1
