Icr-100x 37, Osd menu – IC Realtime 480TVL Super Night Vision Outdoor AF 22X Zoom Camera (ICR200X) User Manual
Page 29
Speed Dome Camera Instruction Manual
37/57
Privacy Zone Mask Area Setup
EDIT MASK 1
------------------------
MOVE TO TARGET POSITION
[NEAR:SELECT/FAR:CANCEL]
Privacy Zone Mask Size Setup
EDIT MASK 1
------------------------
[ :ADJUST MASK WIDTH]
[ :ADJUST MASK HEIGHT]
[NEAR:SAVE /FAR:CANCEL]
Move your camera to an area to mask. Then a mask and the
menu to adjust the mask size will be displayed.
Adjusts the mask size. Use the joystick or the arrow buttons
of your controller to adjust mask size.
z
(Left/Right)
Adjusts the mask width.
z
(Up/Down)
Adjusts the mask height.
OSD MENU
4
