40
• TILT ANGLE
Move to TILT ANGLE and Press the MANU KEY. To finish, press the MANU KEY.
Caution
1. ZOOM is automatically switched to 1x.
2. WDR, ATW are set to FACTORY DEFAULT.
3. If set an AUTO PAN with TILT over 90°, PAN/TILT automatically moves to the position
-20°~90° and TILT is limited to 90°.
MENU Shift: UP, DOWN, LEFT & RIGHT KEYS
MENU Open: IRIS OPEN KEY
MENU Close: IRIS CLOSE KEY
For Privacy protection, use and set MOSAIC ZONE.
• AREA SEL
Up to 8 PRIVACY ZONES can be defined.
• AREA DEFINE
OFF: PRIVACY ZONE is not activated.
ON: PRIVACY ZONE is activated.
• AREA COLOUR
The colour of the MOSAIC ZONE is selectable.
• AREA NEW SET
OFF: Previous PRVIACY ZONE is activated.
ON: New PRIVACY ZONE is set up from the current PAN/TILT position
(when switching from OFF to ON the PRIVACY ZONE appears in the centre on the screen).
4. ZONE SET
1. AREA SEL 1 ~ 8
2. AREA DEFINE OFF / ON
3. AREA COLOUR BLACK / MOSAIC
4. AREA NEW SET OFF / ON
5. HEIGHT EDIT XXX
6. WIDTH EDIT XXX
7. PAN ANGLE XXX
8. TILT ANGLE XXX
9. EXIT
