39
• PATT DEFINE
OFF: PATTERN is cancelled
ON: PATTERN is set up.
If operating in AUTO RUN, PATT DEFINE should to be set to ON.
• NAME
Changes the PATTERN Name.
The method for setting up PATTERN NAME is as follows:
1. Change PATTERN NAME DEF from OFF to ON and press the IRIS OPEN KEY.
2. Changing the name uses the same method as shown in “1.3CAMERA NAME DISPLAY”.
• PATT RECORD
OFF: PATTERN is not memorised.
ON: PATTERN is memorised.
How to set up a PATTERN
1. Change PATT RECORD from OFF to ON and press the IRIS OPEN KEY.
PAN/TILT Shift: UP, DOWN, LEFT & RIGHT
2. Move PAN/TILT to the desired position before starting PATTERN.
3. Press the IRIS OPEN KEY to start the process
4. Press the IRIS CLOSE to save the process.
Caution
1. If there is no PAN/TILT movement, no PATTERN is memorised.
2. The values applied for WDR and ATW are those set on the OSD.
3. If a PATTERN is set with a TILT angle over 90°, PAN/TILT automatically moves to the
position -20°~90° and TILT is limited to 90°
MEMORY FILL XXX ( Recorded )
START IRIS OPEN
EXIT IRIS CLOSE
3.5 AUTO PAN
1.TILT ANGLE:
2. PAN SPEED 2°,5°,10°,20°/S
3. DIRECTION CW / CCW
4. EXIT
PAN is a 360° rotation according to the setting values - TILT ANGLE, DIRECTION and SPEED.
