IC Realtime The Sentinal WDR 36x Optical Zoom, 32x Digital Zoom IR PTZ Camera User Manual
Page 25
25
2.3 ATW
1. ATW MODE AUTO-MANUAL
2. ONE PUSH TRG SET
3. MANUAL RED 0 ~ 255
4. MANUAL BLUE 0 ~ 255
5. EXIT
Menu Shift :
UP, DOWN, LEFT &RIGHT KEYS
Menu Open:
IRIS OPEN KEY
Menu Close:
IRIS CLOSE KEY
A White Balance setting must be specified and be appropriate for the ambient lighting
conditions.
• ATW MODE AUTO
White Balance is automatically compensated.
• ATW MODE ] ATW
White Balance is automatically compensated when the colour temperature range is
2500°K~9500°K.
• ATW MODE ] OUTDOOR
White Balance is optimised for an outdoor environment.
• ATW MODE ] INDOOR
White Balance is optimised for an indoor environment.
• ATW MODE ] ONE PUSH
White Balance is optimised for the current lighting conditions. If the lighting conditions
change, the White Balance should be readjusted. It operates by pressing the IRIS OPEN KEY
when SET is on.
• ATW MODE ] MANUAL
White Balance is manually adjustable using the RED and BLUE gain controls.
