13
• RS485 Address Settings
ID setting for DP22 switches SW1~SW7 DIP Switch setting 1-ON, 0-OFF
DIP SW ID DIP SW ID DIP SW ID
1000000 1 1010100 21 1001010 41
0100000 2 0110100 22 0101010 42
1100000 3 1110100 23 1101010 43
0010000 4 0001100 24 0011010 44
1010000 5 1001100 25 1011010 45
0110000 6 0101100 26 0111010 46
1110000 7 1101100 27 1111010 47
0001000 8 0011100 28 0000110 48
1001000 9 1011100 29 1000110 49
0101000 10 0111100 30 0100110 50
1101000 11 1111100 31 1100110 51
0011000 12 0000010 32 0010110 52
1011000 13 1000010 33 1010110 53
0111000 14 0100010 34 0110110 54
1111000 15 1100010 35 1110110 55
0000100 16 0010010 36 0001110 56
1000100 17 1010010 37 1001110 57
0100100 18 0110010 38 0101110 58
1100100 19 1110010 39 1101110 59
0010100 20 0001010 40 0011110 60
1011110 61 0010101 84 1101011 107
0111110 62 1010101 85 0011011 108
1111110 63 0110101 86 1011011 109
0000001 64 1110101 87 0111011 110
1000001 65 0001101 88 1111011 111
1100001 67 0101101 90 1000111 113
0010001 68 1101101 91 0100111 114
1010001 69 0011101 92 1100111 115
0100001 66 1001101 89 0000111 112
0110001 70 1011101 93 0010111 116
1110001 71 0111101 94 1010111 117
0001001 72 1111101 95 0110111 118
1001001 73 0000011 96 1110111 119
0101001 74 1000011 97 0001111 120
1101001 75 0100011 98 1001111 121
0011001 76 1100011 99 0101111 122
