System information – IC Realtime The Sentinal WDR 36x Optical Zoom, 32x Digital Zoom IR PTZ Camera User Manual
Page 20
20
System information
The diagrams shown in the previous section illustrated the overall structure of the setup menu. In this
section, descriptions of the features within the setup menu will enable users of the camera to tailor it to
their personal needs.
Selection:
UP, DOWN, LEFT & RIGHT KEYS
Menu Open: IRIS OPEN KEY
Menu Close: IRIS CLOSE KEY
MAIN MENU
1. PAN TILT SET
2. CAMERA SET
3. AUTOSEQ SET
4. ZONE SET
5. ALARM SET
6. WIPER SET
7. INITIALISE SET
8. EXIT
1. PAN TILT SET
1. ID DISPLAY
ON / OFF
2. P/T DISPLAY
ON / OFF
3. CAMERA NAME
OFF / ON
4. MANUAL SPEED
10~110° / SECOND
5. PROPO. P/T
ON / OFF
6. DIGITAL FLIP
ON / OFF
7. IMAGE HOLD
OFF / ON
8. INSTALLATION
NORMAL / INVERT
9. AUTO REFRESH
5~240
10. EXIT
