38
3.4 PATTERN
A PATTERN is a memorised
1. PATT NUMBER 1~2
2. PATT DEFINE OFF / ON
3. NAME PATTERN001
4. PATTNAME DEF OFF /
5. PATT RECORD OFF /
6. PATT SPEED 2°,5,10,20°/S
7. EXIT
MENU Shift: UP, DOWN, LEFT & RIGHT KEYS
MENU Open: IRIS OPEN KEY
MENU Close: IRIS CLOSE KEY
PAN Shift: LEFT, RIGHT KEY
2. After moving to the desired position, press the IRIS OPEN KEY.
• PAN END POS
This sets up the end position for the SCAN.
The method for setting up PAN END POS is the same as for PAN START POS.
• TILT POS
This sets up the TILT angle in the SCAN.
Set up is similar to “PAN START POS” but the UP, DOWN keys should be used.
• SCAN SPEED
Sets up the SCAN Speed.
The speed can be set between 2°/second (slow) ~ 20°/second (fast).
Caution
1. The values applied for WDR and ATW are those set on the OSD.
2. Set up angles of the initial and end location for the SCAN should not be over 180°.
3. Use AUTOPAN (A.PAN) for a continual PAN in SCAN.
4. If setting a SCAN with a TILT over 90°, PAN/TILT automatically moves to the position
-20°~90° and TILT is limited to 90°
PAN START POSITION SET
PAN START POSITION XXX
EXIT IRIS CLOSE
