IC Realtime The Sentinal WDR 36x Optical Zoom, 32x Digital Zoom IR PTZ Camera User Manual
Page 33
33
•
SCAN
PAN moves from the start point to the end point and up to 5 Scans can be set up.
•
PATTERN
The operational path of PAN/TILT actions is saved and PATTERN plays and repeats these
PAN/TITL actions.
•
AUTO PAN
Continually PANs.
•
AUTORUN
OFF: The camera is in a Standby condition.
SEQ, TOUR, SCAN, PATT, A.PAN: Are executed automatically after the user exits the OSD
MENU.
•
HOMEPOSITION
If there is any loss of power the camera goes to this programmed Preset.
If AUTORUN is set, the camera does not go to the programmed Preset.
Menu Shift:
UP, DOWN, LEFT & RIGHT KEYS
Menu Open: IRIS OPEN KEY
Menu Close:
IRIS CLOSE KEY
3.1 PRESET
This function, after programming, moves the camera to a designated position.
1. PRESET NO 1~128
2. PRESET DEFINE OFF /
3. PRESET NAME OFF /
4. P/T POSITION XXX / YYY
5. FOCUS IN BW AUTO / ZOOMTG / MANUAL
6. WDR OFF / ON
7. ATW SET
8. EXIT
