33

ALARM NO

01

ACTION

NONE

CONTACT

N/O

PRESET

001

AUTO SCAN :001

CRUISE :001

RELAY OUT

OFFS

RESET DELAY :3S

SAVE

BACK

EXIT

• PRESET: The speed dome will go to the selected preset at the specified time if you

select the time task as preset. The value ranges from 1 to 80.

• SCAN: The speed dome will go to the selected scan at the specified time if you select the

time task as scan. The value ranges from 1 to 5.

• TOUR: The speed dome will go to the selected preset at the specified time if you select

the time task as tour. The value ranges from 1 to 8.

• PATTERN: The speed dome will go to the selected pattern at the specified time if you

select the time task as pattern. The value ranges from 1 to 5.

• SAVE: After you completed the above setup, you need to move the cursor here and then

click confirm button to save current time setup.

• BACK: Go back to the previous menu.
• EXIT: Log out the system menu.

4.4.5 Alarm

Setup








Move the cursor to highlight ALARM SETTING button and then click confirm button.
z

ALARM NO: Here is to set alarm input. Alarm input value ranges from 1 to 7. Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

z

ACTION: Action on alarm function. It includes NONE/PRESET/AUTO SCAN/TOURING

functions. Please use the left/right button on the keyboard or in the speed dome terminal
menu to set.

z

CONTACT

:You can set system activation operation once alarm occurred. There are two

alarm signal mode: normal open (N/O) and normal closed (N/C). Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.

z

PRESET

NO

:Please use the left/right button on the keyboard or in the speed dome

terminal menu to set. The camera will turn to the specified preset to monitor after alarm
occurs.

z

AUTO

SCAN

:Please use the left/right button on the keyboard or in the speed dome

terminal menu to set. The camera will begin auto scan after alarm occurs.

z

CRUISE

:Please use the left/right button on the keyboard or in the speed dome terminal

menu to set. The camera will begin auto cruise when alarm occurs.

z

RELAY OUT: Here is to set relay alarm mode and reset time. There are several options:

off/1→5S/2→5S/1&2→5S.
