25

DAY/NIGHT :AUTO

DAY TIME :07H 00M

NIGHT TIME : 19H 00M

SAVE

BACK

EXIT

o

Auto: It becomes valid after you set the exposure compensation, backlight
compensation (BLC), slow shutter, wide dynamic region (WDR).

o

Manual: It becomes valid after you set the gain setting, shutter, iris setting, wide
dynamic region (WDR).

o

AV: It becomes valid after you set the exposure setting, iris setting, wide
dynamic region (WDR).

o

TV: It becomes valid after you set the shutter setting, exposure compensation,
wide dynamic region (WDR).

z

GAIN SETTING: The value ranges from 1 to 16. Default value is 2. Please use the left/right

button on the keyboard or in the speed dome terminal menu to set.

z

SHUTTER: You can set shutter speed here. The value ranges from 1/3 to 1/10000. Default

value is 1/50. Please use the left/right button on the keyboard or in the speed dome terminal
menu to set.

z

IRIS SETTING: The value ranges from 1 to 18. Default value is 11. Please use the left/right

button on the keyboard or in the speed dome terminal menu to set.

z

EXPOSURE COM: The value ranges from 1 to 15. Default value is 8. Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

z

SLOW AE; in the strong light environment, you can lower the camera exposure speed to

capture the image and enhance the definition. The value ranges from 1 to 16. The bigger the
value, the higher the exposure speed. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set. Please make sure your camera supports this
function.

z

SLOW SHUTTER: In lower illumination environment, you can lower the cameras auto

exposure time to capture the image and enhance the definition. Please note for the
moving object, the image trail phenomenon may occur.

Please use the left/right button

on the keyboard or in the speed dome terminal menu to set.

z

BLC: It is an abbreviation for back light compensation. System can compensate the object in

the dark light to achieve a clear video. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.

z

WDR ENBALE: It is an abbreviation for wide dynamic region. Please make sure your

camera supports current function. This function can adjust the video brightness when the
contrast between the strong light and the dark light is too high. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.


4.4.3.3 Day/Night Setting

Move the cursor to DAY/NIGHT SETTING and then click confirm button, you can go to the
submenu.





z

DAY/NIGHT: There are four options: auto/time/night/day. Please use the left/right button on

the keyboard or in the speed dome terminal menu to set.
