21

INITIAL INFORMATION

ADDR INFORMATION

SYSTEM TIME SETTING

SET NORTH

LANGUAGE : ENGLISH

PTZ AUTO STOP

FACTORY DEFAULT

RESTART

BACK

EXIT

z

EXIT

: Log out the system menu.

4.4 Menu Operation

In the speed dome main menu, you can use the left/right button on the keyboard or in the speed
dome terminal menu to configure the system menu. Before setup, please move the cursor to the
current item you want to configure.
z

In main menu, please click confirm button to go to the sub menu or use left/right key to

configure setup.

z

Use up/down button to select back option and then click confirm button to go back to the

previous menu.

z

Use up/down button to select exit option and then click confirm button to log out system

menu.

z

All setup here will not lose when encounter power failure.

4.4.1

System Information






z

INITIAL INFORMATION: Move the cursor to INITIAL INFORMATION and then click confirm

button to go to the third submenu.

z

ADDR INFORMATION: Move the cursor to SITE INFORMATION and then click confirm

button to go to the third submenu.

z

SYSTEM TIME SETTING: Move the cursor to SYSTEM TIME SETTING and then click

confirm button to go to the third submenu.

z

SET NORTH DIRECTION: Set dome benchmark direction so that you can know the angel

between the benchmark and then current location. Please move the cursor to the option and
then click confirm button until you see O.K. Now you have set north direction.

z

LANGUAGE: The dome menu language. There are several languages for you to select.

Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

PTZ AUTO STOP: The PTZ stop the corresponding operation once it reaches the time you

specified here. The option includes: close\5S\10S\15S\20S\25S\30S and etc. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.

z

FACTORY DEFAULT: Restore dome factory default setup. Please move the cursor to the

option and then click confirm button until you see O.K. Now you can see the IP dome begin
rebooting to restore factory default setup.

z

RESTART: Reboot the speed dome.

z

BACK: Go back to the previous menu.

z

EXIT: Log out system menu.

4.4.1.1

Initialization information
