22

ADDR

001-H

BAUD RATE :9600

PARITY

NONE

PROTOCOL :PELCO-D

MODEL

SD6663-HN

TEMP : 032℃

SOFTWARE :v1.04.3

BACK

EXIT

Move the cursor to INITIAL INFORMATION and then click confirm button, you can see the above
interface.
Here you can view dome basic information.

4.4.1.2 Address Information



Move the cursor to SITE INFORMATION and then click confirm button.
z

ADDR TYPE: There are two options: soft and hard. Please use the left/right button on the

keyboard or in the speed dome terminal menu to set.

z

ADDR-HARD: It is an address you set in the dial switch. You can not modify it through

software.

z

ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify

dome address. The value ranges from 1 to 255.

z

BACK: Go back to the previous menu.

z

EXIT: Log out system menu.

4.4.1.3 System Time Setting






z

Move the cursor to SYSTEM TIME SETING and then click confirm button, you can go to the

third submenu. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set. After completed setup, please click confirm button to save current
setup. After you see speed dome menu displays OK, you can see the setup is valid now.

4.4.2 Display

Setting







ADDR TYPE : HARD

ADDR-HARD : 001

ADDR-SOFT : 001

BACK

EXIT

YEAR : 2009

MONTH : 001

DATE : 017

WEEK : SUNDAY

HOUR : 013

MINU: : 052

SAVE

BACK

EXIT

PRESET TITLE :ON

AZIMUTH DISP :ON

TIME DISP :OFF

POSITION :OFF

ZOOM DISP :OFF

INSIDE TEMP :℃

OUTSIDE T&H :OFF

IDLE TIME :1 Min

TITLE DISP :OFF

BACK

EXIT
