30

Pattern function can memory PTZ operation and camera focus zoom in and zoom out.
From the start position, dome begins auto movement repeatedly.
This series IP dome supports maximum 5 patterns and one pattern can max support 400
commands.
Move the cursor to PATTERN and click confirm button.

z

PATTERN

NO

: Here is to set pattern number. The value ranges from 1 to 5. Please click

left/right key to configure.

z

PROGRAM START: Here is to memorize pattern starting point. An icon OK pops up in

screen to prompt you system begins memory pattern.

z

PROGRAM

STOP

:Here is to set pattern stop point. After all the movement, move the

cursor to PROGRAM STOP and then click confirm button. Now you have set one pattern.
System pops up an icon OK to prompt you system has memories one pattern.

z

RUN

:Here is to activate pattern. Input pattern number, move the cursor to RUN and click

confirm button, system begins running pattern.

z

STOP: Here is to stop current pattern. Input pattern number, move the cursor to STOP and

click confirm button. System stops current pattern.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.

Note:

z

The dwell time between two orders should be less than one minute, otherwise system will

set to default value as one minute.

z

After click PROGRAM STOP, do not click CALL button before icon

“●” disappears

completely.

z

Any manual operation during the pattern procedure will terminate current dome pattern

operation.


4.4.4.6 Privacy Masking (Window blank)

Please make sure you current camera supports this function.









Move the cursor to PRIVACY ZONE and click confirm button, system goes to privacy mask setup
interface.

For SONY series cameras
There are maximum 8 privacy mask zones in 360 degrees .The tilt angle ranges from 0 to 70
degrees.

For HITACHI series cameras

PRIVACY NO :001

ACTIVATE : OFF

RESIZE : ↑

DELETE

SAVE

BACK

EXIT
