28

SCAN NO : 001

SET LEFT LIMIT

SET RIGHT LIMIT

SCAN SPEED :160

RUN

STOP

BACK

EXIT

to begin rotation. Call preset 33 to enable PTZ 180 degrees rotation. Call preset 34 to set
dome position as 0.

z

Set preset: Set preset 26 or 92 to set scan left limit. Set preset 27 or 93 to set scan right

limit. Set preset 22 or 79 to begin record. Set preset 23 or 80 to stop record.


4.4.4.2 Pan



Move the cursor to PAN button and then click confirm button to go to setup interface.
z

PAN SPEED: Set dome rotation speed. The Value ranges from 1 to 255. Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

z

RUN: Move the cursor to call item and then click confirm button. The dome begins 360

degrees continuous rotation.

z

STOP: Highlight stop item and then click confirm button. The dome stops rotation.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.


4.4.4.3 Scan





Move the cursor to SCAN button and then click confirm button.

z

SCAN

NO

:Here is to set auto scan number. The value ranges from 1 to 5. Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

z

SET LEFT LIMIT

:Here is to set camera left address. Click confirm button to save current

setup.

z

SET

RIGHT

LIMIT

:Here is to set camera right address. Click confirm button to save current

setup.

z

SCAN SPEED: The value ranges from 1 to 255. Please use the left/right button on the

keyboard or in the speed dome terminal menu to set.

z

RUN: Please input auto scan number first, and then please move the cursor to RUN and

click confirm button to activate auto scan function.

z

STOP: Here is to terminate auto scan function.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.


4.4.4.4 Cruise (Touring)

PAN SPEED :160

RUN

STOP

BACK

EXIT
