26

PRESET

PAN

SCAN

AUTO CRUISE

PATTERN

IDLE MOTION

TIME TASK

PRIVACY MASKING

BACK

EXIT

PICTURE FLIP

:OFF

FREEZE FUNCTION

:OFF

CAMERA FACTORY DEFAULT

CAMERA RESTATRT

BACK

EXIT

z

DAY TIME: Current setup becomes valid when day/night mode is Time. Move the cursor to

DAY TIME item and then click confirm button to go to setup. Please user up/down button to
set the value. After completed setup, please click confirm button to exit and move the cursor
to Save button to save current setup.

z

NIGHT TIME: Current setup becomes valid when day/night mode is Time. Move the cursor

to DAY TIME item and then click confirm button to go to setup. Please user up/down button
to set the value. After completed setup, please click confirm button to exit and move the
cursor to save button to save current setup.

z

SAVE: This button is for DAY TIME and NIGHT TIME setup. After you set the day time (or

night time), you need to move the cursor here and then click confirm button to save current
time setup. For other setups, you do not need to use this button.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.

z

4.4.3.4 Next Page

Move the cursor to NEXT PAGE and then click confirm button, you can go to the submenu.





z

PICTURE FLIP: This function allows you to turn the image rotation 180 degrees. There are

two options: on/off. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.

z

FREEZE FUNCTION: This function allows the system from one preset to another preset,

without showing the video during the PTZ movement. There are two options: on/off. Please
use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

CAMERA FACTORY DEFAULT SETTING: Move the cursor to current item and then click

confirm button to restore factory default setup.

z

CAMERE RESTART: Move the cursor to current item and then click confirm button to reboot

the camera.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.

4.4.4 Function

Setting





Please go back to main menu and move the cursor to FUNCTION SETTING, click confirm button.
You can see the above interface.
