8.2 LAN Mode
For the LAN mode, after you logged in, you can see the main window. See Figure 8-4.
Figure 8-4 Main Interface
There are six sections:
z
Section 1: Monitor channel menu tree
z
Section 2: System menu
z
Section 3: PTZ control
z
Section 4: Video setup and other setup
z
Section 5: Preview window
z
Section 6: Monitor window switch
8.2.1 Monitor Channel Menu Tree
The monitor channel menu tree is shown as in Figure 8-5.
Please note the following figure is for reference only.
