2 nvr6xxv series, 3 nvr7xxn series – IC Realtime 4/8/16/32 Channel 2U Network Video Recorder User Manual
Page 30
21
3.2 NVR6XXV Series
3.3 NVR7XXN Series
①
Use the screwdriver to loose the screws of the rear panel and then remove the front cover.
①
Use 4 screws to secure the HDD
②
Put the HDD to the HDD box at the front.
③Pull the HDD knob up when you put the HDD
into the box in case the knob buckle may strike
the front panel.
④
Put the knob back after you insert the HDD
to the SATA board.
