6

Window Split

4/8/9/16-window

Multiple-chann
el Playback

Max 16-channel playback.

Alarm Input

4/8/16-ch series product support 4/8/16-ch alarm input respectively.


6-ch alarm output

Alarm Output

Relay output. Relay (DC 30V 1A,AC 125V 0.5A(Activation output))
Including one controllable DC +12V output.

8 built-in SATA ports

Storage

1 peripheral eSATA port

RS232 Port

One RS232 port to debug transparent COM data.

RS485 port

One RS485 port to control PTZ. Support various protocols.

USB Port

4 peripheral USB ports.

Network
Connection

One RJ45 10/100M/1000M self-adaptive Ethernet port.

Power Port

One power port. AC100~240V 50+2% Hz

Power Button

One power button in the rear panel.

Power Button

One power button in the front panel.

IR Remote
Control
Receiver

One IR remote control receiver in the front panel.

Clock

Built-in clock.

Indication Light

z

16 record status indication lights

z

One system running status indication light.

z

One remote control indication light.

Power
Consumption

40W(Exclude HDD)

Working
Temperature

0℃~+50℃

Working
Humidity

10℅-90℅

Air pressure

86kpa-106kpa

Dimension

440mm*460mm*89mm

Weight

5.5~6.5KG(Exclude HDD)

Installation

Desk installation/Rack installation
