32
Power
Consumptio
n
50W (Exclude HDD)
Working
Temperatur
e 0℃－＋55℃
Working
Humidity 10%－90%
Air
Pressure 86kpa－106kpa
Dimension 2U standard industrial case. 440(W) x460 (D) x89mm(H)
Weight 7.0－8.0KG (Exclude HDD)
General
Parameter
Installation
Mode Desktop/rack installation
1.3.10 960H 2U Series
Parameter
4-ch 8-ch 16-ch
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources Multiplex operations: Multiple-channel record, multiple-channel
playback and network operation simultaneously
Interface User-friendly graphical user interface
Input Devices Front panel, USB mouse
Input Method
Arabic number, English character, donation and extension Chinese
(optional)
System
Shortcut
Function Copy/paste operation, USB mouse right-key shortcut menu, double
click USB mouse to switch screen.
Video
Compression
H.264
Compression
Standard
Audio
Compression
G.711A
Video Input
4-CH composite
video input:
(NTSC/PAL) BNC
(1.0V
B
P- P,
B
75Ω)
8-CH composite video
input: (NTSC/PAL)
BNC (1.0V
B
P- P,
B
75Ω)
16-CH composite
video input:
(NTSC/PAL) BNC
(1.0V
B
P- P,
B
75Ω)
Video Output
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
1-ch matrix output.
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (625 line, 50f/s), NTSC (525 line, 60f/s)
Record Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video Partition
1/4
windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows
Monitor
Touring Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
Video monitor
Resolution
(PAL/NTSC)
PAL(625TVL, 50f/s)/NTSC(525TVL, 60f/s)
Real-time monitor：
960H 960 Ч576/960Ч480
