IC Realtime Specialty: Interrogator DVR - a DVR for law enforcement User Manual

Page 85

This main window can be divided into the following sections.
z

Section 1: there are five function buttons: configuration (chapter 7.3), search

(chapter 7.4), alarm (chapter 7.5), about (chapter 7.6), log out (chapter 7.7).

Section 2: there are channel number and five function buttons: open all/start

dialog/refresh/ local play/burning.

Section3: there are PTZ (chapter 7.2.2), color (chapter 7.2.3) button and you can

also select picture path and record path.

Section 4:real-time monitor window. Please note current preview window is circled

by a green rectangle zone.

Section 5: Here you can view window switch button. You can also select video

priority between fluency or real-time.

System monitor window switch supports full screen/1-window/4-window/6-

window/8-window/9-window/13-window/16-window/20-window/25-window/36-
window. See Figure 7-4.

Figure 7-4

Preview window switch. System support 1/4/8/9/16-window real-time preview.

Please you need to have the proper rights to implement preview operation. You can
not preview if you have no right to preview the either channel. See Figure 7-5.

Figure 7-5

Figure 7-6

Section1

Section 2

Section 3

Section 5

Section 4
