REQUIRED CLEARANCES TO COMBUSTIBLE MATERIAL — in. (mm)
Unit Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 (356)
Duct Side of Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 (51)
Side Opposite Ducts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 (356)
Bottom of Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Vertical Discharge First 12 in. (305) of Supply Duct . . . . . . . . . . . 1 (25)
NECESSARY REQUIRED CLEARANCES — in. (mm)
Between Units, Control Box Side . . . . . . . . . . . . . . . . . . . . . 42 (1067)
Unit and Ungrounded Surfaces, Control Box Side . . . . . . . . . . . 36 (914)
Unit and Block or Concrete Walls and Other Grounded
Surfaces, Control Box Side . . . . . . . . . . . . . . . . . . . . . . . . . 42 (1067)
REQUIRED CLEARANCES FOR SERVICING — in. (mm)
Evaporator Coil Access Side . . . . . . . . . . . . . . . . . . . . . . . . . 30 (762)
Control Box Access Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 (762)
(Except for Necessary Requirements)
Unit Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 (914)
Side Opposite Ducts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 (762)
NOTES:
1. Clearances must be maintained to prevent recirculation of air from outdoor-
fan discharge.
2. Dimensions in (
) are in millimeters.
LEGEND
CG
— Center of Gravity
NEC
— National Electrical Code
COND — Condenser
REQ’D — Required
MAT’L — Material
UNIT
50SX
ELECTRICAL
CHARACTERISTICS
UNIT WT
CORNER WT (Lb/Kg)
Lb
Kg
A
B
C
D
042
208/230-1-60, 208/230-3-60, 460-3-60
309
140
84/38
59/27
119/54
47/21
048
208/230-1-60, 208/230-3-60, 460-3-60
340
155
84/38
70/32
133/60
53/24
060
208/230-1-60, 208/230-3-60
359
163
65/30
99/45
120/55
75/34
UNIT
50SX
CENTER OF GRAVITY (in./mm)
X
Y
Z
042
21.0/533
20.1/510
15.4/390
048
21.8/553
19.7/499
15.4/390
060
22.2/565
19.8/503
13.4/340
Fig. 8 — Dimensions; Units 50SX042-060 Without Base Rail (cont)
