1.Your Great Planes CAP 232 ARF should not be considered
a toy, but rather a sophisticated, working model that functions
very much like a full-size airplane. Because of its
performance capabilities, the Great Planes CAP 232 ARF, if
not assembled and operated correctly, could possibly cause
injury to yourself or spectators and damage to property.
2. You must assemble the model according to the
instructions. Do not alter or modify the model, as doing
so may result in an unsafe or unflyable model. In a few cases
the instructions may differ slightly from the photos. In those
instances the written instructions should be considered
as correct.
3. You must take time to build straight, true and strong.
4. You must use an R/C radio system that is in first-class
condition and a correctly sized engine and components (fuel
tank, wheels, etc.) throughout the building process.
5. You must correctly install all R/C and other components so
that the model operates correctly on the ground and in the air.
6. You must check the operation of the model before every
flight to insure that all equipment is operating and that the
model has remained structurally sound. Be sure to check
clevises or other connectors often and replace them if they
show any signs of wear or fatigue.
7. If you are not an experienced pilot or have not flown this
type of model before, we recommend that you get the
assistance of an experienced pilot in your R/C club for your
first flights. If you’re not a member of a club, your local hobby
shop has information about clubs in your area whose
membership includes experienced pilots.
8. While this ARF has been flight tested to exceed normal
use, if the plane will be used for extremely high stress flying,
such as racing, or if an engine larger than one in the
recommended range is used, the modeler is responsible for
taking steps to reinforce the high stress points and/or
substituting hardware more suitable for the increased stress.
9. WARNING: The cowl, wheel pants and wing struts
included in this kit are made of fiberglass, the fibers of which
may cause eye, skin and respiratory tract irritation. Never
blow into a part (wheel pant, cowl) to remove fiberglass dust,
as the dust will blow back into your eyes. Always wear safety
goggles, a particle mask and rubber gloves when grinding,
drilling and sanding fiberglass parts. Vacuum the parts and
the work area thoroughly after working with fiberglass parts.
Remember: Take your time and follow the instructions to
end up with a well-built model that is straight and true.
This is a partial list of items required to finish the Great
Planes CAP 232 ARF that may require planning or decision
making before starting to build. Order numbers are provided
in parentheses.
❏
4-channel radio minimum, 6-channel or greater
recommended for mixing options.
❏
7-channel dual conversion receiver.
❏
(6) standard size servos capable of a minimum of 70 in
oz of torque, i.e. the S3305 SERVO High Torque w/Metal
Gears from Futaba
® (FUTM0045).
❏
(1) Throttle servo standard size, i.e. S3004 BB Standard
Servo from Futaba (FUTM0004).
❏
4.8v - 6.0v receiver pack 1100 mAh or greater.
❏
Propeller as recommended for your engine choice.
❏
(2) Command Extension 6" [153 mm] with Futaba J
Connectors (HCAM2000).
❏
Ignition Kill Switch.
If using an 8-channel computerized radio or greater, you
also need:
❏
(6) Command Servo Extensions 24" [610 mm] with
Futaba J Connectors (HCAM2200).
If using a 6-channel computerized radio you will need:
❏
(2) Command Extension 24" [610 mm] with Futaba J
Connectors (HCAM2200).
❏
(2) SR10 Dual Servo Reverser (FUTM4150) for elevators
and rudder.
If using a 4-channel radio you will need:
❏
(2) SR10 Dual Servo Reverser (FUTM4150) for
elevators, ailerons and rudder.
❏
(1) Command Y-Harness with Futaba J Connectors
(HCAM2500) for ailerons.
Radio Equipment
DECISIONS YOU MUST MAKE
We, as the kit manufacturer, provide you with a top quality,
thoroughly tested kit and instructions, but ultimately the
quality and flyability of your finished model depends on
how you build it; therefore, we cannot in any way
guarantee the performance of your completed model, and
no representations are expressed or implied as to the
performance or safety of your completed model. PROTECT YOUR MODEL, YOURSELF
& OTHERS...FOLLOW THESE
IMPORTANT SAFETY PRECAUTIONS
3
